| Model | Overall dimension (mm) | Limit speed (RPM) | Rated load(N) | Weight | ||||
|---|---|---|---|---|---|---|---|---|
| d | D | B | Grease | Oil lubrication | Cr(N) | Cor(N) | ||
| 292/1060 | 1060 | 1400 | 206 | - | - | - | - | - |
| 292/500 | 500 | 670 | 103 | 500 | - | 2460 | 14800 | 101 |
| 292/800 | 800 | 1060 | 155 | 100 | - | 5620 | 35300 | 339 |
| 292/850 | 850 | 1120 | 160 | 80 | - | 6080 | 38900 | 389 |
| 292/900 | 900 | 1180 | 170 | 60 | - | 6590 | 42000 | 444 |
| 292/950 | 950 | 1250 | 180 | - | - | - | - | - |
| 29230 | 150 | 215 | 39 | - | - | - | - | - |
| 292/530 | 530 | 710 | 109 | 400 | - | 2800 | 16200 | 108 |
| 292/670 | 670 | 900 | 140 | 200 | - | 4440 | 26500 | 224 |
| 292/710 | 710 | 950 | 145 | 150 | - | 4840 | 29400 | 261 |
| 292/750 | 750 | 1000 | 150 | 130 | - | 5180 | 31900 | 293 |
| 29252 | 260 | 360 | 60 | 1200 | - | 838 | 3720 | 18.5 |
| 29264 | 320 | 440 | 73 | 900 | - | 1110 | 5170 | 32.9 |
| 29272 | 360 | 500 | 85 | 750 | - | 1460 | 6450 | 51.8 |
| 29276 | 380 | 520 | 85 | 700 | - | 1580 | 7430 | 52.8 |
| 29284 | 420 | 580 | 95 | 600 | - | 1990 | 9620 | 75.4 |
| 29232 | 160 | 225 | 39 | - | - | - | - | - |
| 29288 | 440 | 600 | 95 | 600 | - | 2060 | 9830 | 77.9 |
| 29234 | 170 | 240 | 42 | - | - | - | - | - |
| 29240 | 200 | 280 | 48 | 1600 | - | 536 | 2270 | 8.9 |
